URETHANE FRONT SWAY BAR TO FRAME QTY NEEDED PER CAR MODEL W108 (250/280) W109 (300/6.3) W110 (190/200/230) W111 (220/250/280) W112 (300) W113 (230/250/280SL) Front sway bar to frame - 22mm 2 2 early 2 late Front sway bar to frame - 23.85mm 2 2 late Front sway bar to frame - 20.34mm 2 2 early 2 late NOTE: Before selecting a front sway bar frame bushing, please measure the bar diameter first. Use either a flexible tape or a pair of calipers as shown. Do not use a flat ruler. With Calipers With flexible tape If using an inch tape – take measurement and divide by 3.142 to get the diameter. To convert from inches to mm, simply multiply by 25.4. In both cases, this sway bar measures 24mm.
URETHANE FRONT LEAF SPRING BUSHING QTY NEEDED PER CAR MODEL W108 (250/280) W110 (190/200/230) W111 (220/250/280) W113 (230/250/280SL) 4 4 4 4
URETHANE FRONT LEAF SPRING BUSHING QTY NEEDED PER CAR MODEL W109 (300/6.3) W112 (300) 4 4
URETHANE TRAILING ARM REAR (TO AXLE) QTY NEEDED PER CAR MODEL SOLD PER BUSHING SLEEVE NOT SOLD SEPERATELY W108 (250/280) W109 (300/6.3) W110 (190/200/230) W111 (220/250/280) W112 (300) W113 (230/250/280SL) 4 4
HOSE SOLD IN METER LENGTHS, PLEASE STATE CHASSIS # IN SHIPPING INSTRUCTIONS BOX WHEN ORDERINGArticle code: v.nr.0004352182
Late 280SL HOSE WITH FITTED ENDS AND CHECK VALVE. For 280SL FROM CHASSIS # 011948 TO PRODUCTION END. EARLIER HOSE WITH 90 DEGREE ENDS IS NO LONGER AVAILABLE.Article code: v.nr.1134300629
RUBBER GASKET/SEAL FOR BETWEEN VALVE COVER AND CYLINDER HEAD.Article code: v.nr.1300160221
VALVE COVER TUBE - PLASTIC 230SL — Chassis 113.042 1963 - 1966 Base Convertible 2.3L L6 250SE — Chassis 111.023 1966 - 1967 Base Convertible 2.5L L6 250SE — Chassis 108/111 1966 - 1967 Base Coupe 2.5L L6 250SL — Chassis 113.043 1967 Base Convertible 2.5L L6 280SE — Chassis 108/111 1968 - 1969 Base All 2.8L L6
BRASS OR COPPER GUIDE IN CYLIDER HEAD FOR INTAKE VALVE. STANDARD SIZE 14X9X55. 6 PER CAR.Article code: v.nr.1300500024
BRASS OR COPPER GUIDE IN CYLINDER HEAD FOR INTAKE VALVES. REPAIR SIZE OF +.001 OVER STANDARD 14mm O.D. LARGER REPAIR SIZES ARE AVAILABLE UPON SPECIAL REQUEST.Article code: v.nr.1300500124
BRASS OR COPPER GUIDE IN CYLIDER HEAD FOR INTAKE VALVE. STANDARD SIZE 14X9X55. 6 PER CAR.
HALF MOON SHAPED COLLET TO RETAIN INTAKE & EXHAUST VALVE AT TOP SHAFT POINT OF VALVE. FOR 250 & 280SL, 2 PER VALVE, 24 PER CAR. WILL NOT FIT 230SL.Article code: v.nr.1150530026
HALF MOON SHAPED COLLET TO RETAIN INTAKE & EXHAUST VALVES AT TOP SHAFT SIDE OF VALVE. 230SL ONLY, 2 PER VALVE, 24 PER CAR.Article code: v.nr.1800530627
Front Subframe to Leaf Spring Spacer. All W113 Pagoda models from 1963 to 1971
Rubber sleeve that bundles and protects water hose and breather line across top of engine from V/C to air intakeArticle code: v.nr.0079977782
3 Hole fan mount, used w/o fan clutch, long version.Article code: v.nr.1152001620
Angled, fitted hose from top of W/P housing.Article code: v.nr.1088310394
USED WITH SHIFTER BUSHINGS AT BALL ON SHIFT LEVER FOR STD. SHIFT.
WILL COME COMPLETE WITH CENTER CAP AND LUG BOLTS. EXACT REPRODUCTION.Article code: v.nr.1264002302
REPAIR KITS NOT AVAILABLE AT THIS TIME. PLEASE SEE COMPLETE CYLINDER # 42-2020.Article code: v.nr.0005861242
FOR 230SL ENGINES WITH 24mm DIAMETER WRIST PINS. CHECK CLOSELY AS SOME 230SL ENGINES WERE MODIFIED TO HAVE 25mm WRIST PINS.Article code: v.nr.1270380050
FOR 230 & 250SLs WITH 25mm WRIST PINS. CHECK CLOSELY AS MANY 230SL ENGINES ORIGINALLY HAD 24mm WRIST PINS.
FOR 280SL ENGINES ONLY, 25mm DIAMETER. WILL NOT FIT 230 & 250SL ENGINES.Article code: v.nr.1300380150
